Key features: 8 10/100/1000 Mbps Gigabit Ports Auto MDI/MDIX Crossover for all ports Store-and-forward Switching Scheme Full/half-duplex for Ethernet/Fast Ethernet Speeds IEEE 802.3x Flow Control Plug-and-play Installation Built-in D-link Green Technology RoHS Compliant IEEE 802.1p QoS (4 Queues, ...viac
Key features:
8 10/100/1000 Mbps Gigabit Ports
Auto MDI/MDIX Crossover for all ports
Store-and-forward Switching Scheme
Full/half-duplex for Ethernet/Fast Ethernet Speeds
IEEE 802.3x Flow Control
Plug-and-play Installation
Built-in D-link Green Technology
RoHS Compliant
IEEE 802.1p QoS (4 Queues, Strict Mode)
Supports Cable Diagnostics
Supports 9720 KBytes Jumbo Frames
Switching capacity:
16 Gbps
Standards:
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
ANSI/IEEE 802.3 NWay Auto-negotiation
IEEE 802.3x Flow Control
IEEE 802.1p QoS
PoE features:
Supports IEEE 802.3af
Supplies power to PD: up to 15.4 Watts
Total PoE budget: 52 Watts
PoE port count/Average PoE watts per port: 4 (Port 1 - 4) / 13 Watts
Media interface exchange:
Auto MDI/MDIX adjustment for all ports
LED indicators:
Per port: Link/Activity/Speed/PoE Status
Per device: Power/PoE Max
Transmission method:
Store-and-forward
MAC address table:
4K Entries per device
Packet filtering/forwarding rates:
Ethernet: 14,880 pps per port
Fast Ethernet: 148,800 pps per port
Gigabit Ethernet: 1,488,000 pps per port
RAM buffer:
192 KBytes per device
Power consumption:
Power On (Standby): DC input: 0.48 Watts, AC input: 2.1 Watts
Maximum (PoE Off): DC input: 4.48 Watts, AC input: 6.2 Watts
Maximum (PoE On): DC input: 57.83 Watts, AC input: 63.2 Watts
Power adapter:
AC input: 100 to 240 VAC, 50/60 Hz
DC output: DC 48 V/1.25 A (60 Watts)
Temperatures:
Device: 0 to 50 °C (32 to 122 °F)
External Power Adapter: 0 to 40 °C (32 to 104 °F)
Storage: -40 to 70 °C (104 to 158 °F)
Dimensions (W x D x H):
190 x 120 x 38 mm
Certifications:
FCC Class B
ICES-003 Class B
CE Class B
C-Tick Class B
VCCI Class B
cUL
LVD
