Tenda W368R

Technické parametry :.2X INTEGROVANÉ ANTENY.Vstuné napätie : AC 110~240V.Výstupné napätie : AC 9V/ A.Spotreba : 6W.Prevádzková teplota : 0~40 stupňov C.Skladová teplota : -40~70 stupňov C.Frekvencia : 2.4GHz.Štandardy : IEEE 802.11 Standard Podporovaný 802.11n/ /.Vysielací výkon : 20dBm (max.).Citlivosť : 54M:-74dBm@10% PER; 11M:-85dBm@8% PER;6M:-88dBm@10% PER; 1M:-90dBm@8% PER.Anténa : vnútorné antény so ziskom 2dBi.Bezpečnosť : WEP, WPA-PSK/ PA2-PSK, WPA/ PA2.W368R utilizes advanced MIMO technology and increases over 6 times transmission range of ordinary 802.11g products. Compatible with IEEE802.11n (Draft 2.0) and IEEE802.11g/ standards, it can provide up to 300Mbps stable transmission rate. Additionally, it includes router, wireless access point, four-port switch and firewall in one, dedicated to SOHOs (Small Office/ ome Office) and family networking. In addition, URL and MAC address filtering can take it easy for parents and network administrator to manage network life, and QoS bandwidth control over specific computer’s downloading speed is supported as well. WDS (Wireless Distribution System) function supports for bridging more wireless routers and increasing wireless coverage area. Moreover, UPnP and WMM support can smooth your MSN voice better, and the included Setup Wizard on CD-ROM will be easy and fast for non-savvy users to install the device and access to the Internet.Includes router, wireless access point, four-port switch and firewall in one.Provides up to 300Mbps uploading and downloading speed.Supports two WPS (Wi-Fi Protected Setup) encryption methods: PBC and PIN.Compliant to IEEE802.11n, IEEE802.11g, IEEE802.11b, IEEE802.3 and IEEE802.3u standards.Supports over 6 times transmission range of 11G products.Supports 64/ 28-bit WEP, WPA, WPA2, WPA/ PA2 encryption methods.Supports RTS/ TS protocol and data partitioning function.Provides one 10/ 00Mbps Auto-Negotiation Ethernet WAN port.Provides four 10/ 00Mbps Auto-Negotiation Ethernet LAN ports.Supports xDSL/ able MODEM, static and dynamic IP in community networking.Supports remote/ ocal Web management.Supports WMM to better smooth your voice and video.Supports SSID stealth mode and access control based over MAC address (up to 30 entries).Supports Auto MDI/ DIX.Supports wireless Roaming technology for high-efficient wireless connections.Supports auto negotiation/ anual mode for 802.11b/ 02.11g/ 02.11n.Supports UPnP and DDNS.Supports Firefox 1.0, IE5.5 or above.Supports SNTP.Supports virtual server, DMZ host.Built-in firewall for hacker"s attack prevention.Supports DHCP server/ lient.Supports auto wireless channel selection.Supports LAN access control to the Internet.Provides syslog to record the status of the router.Supports WDS wireless network extension.Supports QoS function.Built-in two omni-directional antenn.Input Voltage Range AC 110~240VOutput Voltage RangeAC 9V, A Consumption6WOperating Temperature0? ~ 40? Storage Temperature-40? ~ 70? O/ Power20dbm Operating Humidity10% ~ 90% RH non-condensingStorage Humidity5% ~ 90% RH non-condensingAntennaNon-detachable internal antenna (2dBi) Frequency Range2.4GHzSensitivity54M:-74dBm@10% PER; 11M:-85dBm@8% PER;6M:-88dBm@10% PER; 1M:-90dBm@8% PERWLAN›LAN93Mbps WLAN›WLAN93Mbps DHCP?Virtual Server?IP Address192.168.0.1User NamePasswordadminadminDHCPby defaultenableConnection Mode by defaultDynamic IPSSID by defaultTENDADHCP Pool Range192.168.0.10-192.168.0.100 Dynamic IP?Static IP?PPPOE?PPTP?L2TP?CE?3C?ROHS?Standards and Protocols SupportedIEEE802.3; IEEE802.3u; IEEE802.11b;IEEE802.11g; IEEE802.11n(Draft2.0) Backplane Bandwidth1GFiltering Address Table1KThree-step-installation Suggestion1. Follow the instructions on Quick Installation Guide to connect your cablesEquipmentInternet Explorer 5.5Firefox 1.0 or higherNetwork Adapter?Product Model+NameWireless-N Broadband Router with Internal AntennaPower Supply?Quick Installaiton Guide ?CD-RO.
