Aten CS1316

The CS1316 KVM switch allows access and control up to 256 computers from a single console (keyboard, mouse, and monitor). As many as 16 additional switches can be cascaded* bringing the total number of connected computers to 256 computers that can be controlled from a single keyboard-monitor-mouse console. The switch supports both USB and PS/2 connections for the console and computers.



One USB-PS/2 console controls 16 computers

Cascade up to 2 levels* - control up to 256 computers

Dual Interface - supports computers with PS/2 or USB keyboards and mice

Multiplatform support - Windows 2000/XP/Vista, Linux, Mac, and Sun

Supports multimedia USB keyboards for PC, Mac and Sun

Auto PS/2 and USB interface detection

USB or PS/2 keyboard and mouse emulation - computers boot even when the console focus is elsewhere

Superior video quality - up to 2048 x 1536; DDC2B

Computer selection via front panel pushbuttons, hotkeys and multilingual on-screen display (OSD) menu

Two level password security - only authorized users view and control computers; up to four users and an administrator with a separate profile for each

Auto Scan feature for monitoring user-selected computers

Hot pluggable - add or remove computers without having to power down the switch

Buzzer on/off via hotkey and OSD

Firmware upgradeable

No software installation required

Designed for desktop or rack mount (19" system rack, 1U)

*Cascade function only works with USB KVM cable set connections.



Package Content

1x CS1316 KVM Switch with Rack Mount Kit

1x Console cable

1x Firmware Upgrade cable

1x Grounding wire

1x Foot Pad set (4 pads)

1x Power Adapter (AC Models)

1x User Manual

1x Quick Start Guide
